BQ28Z610是TI公司的一款电池电量监测产品,BQ28Z610是bq28z610 用于 1-2 节锂离子或锂聚合物电池的 Impedance Track 电量监测计,本页介绍了BQ28Z610的产品说明、应用、特性等,并给出了与BQ28Z610相关的TI元器件型号供参考。
BQ28Z610 - bq28z610 用于 1-2 节锂离子或锂聚合物电池的 Impedance Track 电量监测计 - 电池电量监测 - 电池管理产品 - TI公司(Texas Instruments,德州仪器)
- Autonomous Battery Charging Control Using Dedicated Master Mode I2C™ Interface
- Cell Balancing with Internal Bypass To Optimize Battery Health
- High-Side Protection N-CH FET Drive Allows Serial Bus Communication During Fault Conditions
- Programmable Protection Levels for Voltage, Current, and Temperature
- Analog Front End with Two Independent ADCs
- Support for Simultaneous Current and Voltage Sampling
- High-Accuracy Coulomb Counter with Input Offset Error < 1 µV (Typical)
- Supports Down to 1-mΩ Current Sense Resistor While Capable of 1-mA Current Measurement
- Supports Battery Trip Point (BTP) Function for Windows® Integration
- SHA-1 Authentication Responder for Increased Battery Pack Security
- 400-kHz I2C Bus Communications Interface for High-Speed Programming and Data Access
- Compact 12-Pin VSON Package (DRZ)
- Tablet Computing
- Portable and Wearable Health Devices
- Portable Audio Devices
The Texas Instruments bq28z610 device is a highly integrated, accurate, 1-series to 2-series cell gas gauge and protection solution, enabling autonomous charger control and cell balancing.
The bq28z610 device enables autonomous charge control through Master Mode I2C broadcasts of charging current and voltage information, eliminating software overhead that is typically incurred by the system's host controller.
The bq28z610 device provides a fully integrated pack-based solution with a flash programmable custom reduced instruction-set CPU (RISC), safety protection, and authentication for 1- to 2-series cell Li-Ion and Li-Polymer battery packs.
The bq28z610 gas gauge communicates via an I2C compatible interface and combines an ultra-low-power, high-speed TI bqBMP processor, high-accuracy analog measurement capabilities, integrated flash memory, an array of peripheral and communication ports, an N-CH FET drive, and a SHA-1 Authentication transform responder into a complete, high-performance battery management solution.
PART NUMBER | PACKAGE | BODY SIZE (NOM) |
---|---|---|
bq28z610 | VSON (12) | 4 mm × 2.5 mm |
