UA78M33 - 3/4 引脚 500mA 固定 3.3V 正电压稳压器

UA78M33是TI公司(德州仪器)的一款单通道LDO产品,UA78M33是3/4 引脚 500mA 固定 3.3V 正电压稳压器,本站介绍了UA78M33的产品说明、应用、特性等,并给出了与UA78M33相关的TI元器件型号供参考.

UA78M33 - μA78Mxx Positive-Voltage Regulators - TI德州仪器(Texas Instruments)

产品特性
  • 3-Terminal Regulators
  • Output Current up to 500 mA
  • No External Components
  • Internal Thermal-Overload Protection
  • High Power-Dissipation Capability
  • Internal Short-Circuit Current Limiting
  • Output Transistor Safe-Area Compensation
产品应用
  • On-Card Regulation
  • Portable Devices
  • Computing & Servers
  • Telecommunications
产品说明

This series of fixed-voltage integrated-circuit voltage regulators is designed for a wide range of applications. The applications include on-card regulation for elimination of noise and distribution problems associated with single-point regulation. Each of these regulators can deliver up to 500 mA of output current. The internal current-limiting and thermal-shutdown features of these regulators essentially make them immune to overload. In addition to use as fixed-voltage regulators, these devices can be used with external components to obtain adjustable output voltages and currents and also as the power-pass element in precision regulators.

产品器件信息
PART NUMBERPACKAGEBODY SIZE (NOM)
UA78MxxSOT-223 (3)6.50 mm x 3.50 mm
TO-220 (3)10.16 mm x 8.82 mm
TO-252 (3)6.60 mm x 6.10 mm
