TLV1117-18 - 产品图解：
TLV1117-18-单输出 LDO、800mA、固定电压 (1.8V)、内部电流限制、过热保护
TLV1117-18-单通道LDO-线性稳压器(LDO)-电源管理
TI芯片：
承诺原装正品
专营TI德州仪器，真正优化您的供应链
TI产品 - TLV1117-18介绍

TLV1117-18 - 单输出 LDO、800mA、固定电压 (1.8V)、内部电流限制、过热保护

TLV1117-18是TI德州仪器公司的一款单通道LDO产品，TLV1117-18是单输出 LDO、800mA、固定电压 (1.8V)、内部电流限制、过热保护，本站介绍了TLV1117-18的封装应用图解、特点和优点、功能等，并给出了与TLV1117-18相关的TI元器件型号供参考。

TLV1117-18 - 单输出 LDO、800mA、固定电压 (1.8V)、内部电流限制、过热保护 - 单通道LDO - 线性稳压器(LDO) - 德州仪器

产品特性
  • 1.5-V, 1.8-V, 2.5-V, 3.3-V, 5-V, and Adjustable-Output Voltage Options
  • Output Current of 800 mA
  • Specified Dropout Voltage at Multiple Current Levels
  • 0.2% Line Regulation Maximum
  • 0.4% Load Regulation Maximum
产品应用
  • Electronic Points of Sale
  • Medical, Health, and Fitness Applications
  • Printers
  • Appliances and White Goods
  • TV Set-Top Boxes
产品说明

The TLV1117 device is a positive low-dropout voltage regulator designed to provide up to 800mA of output current. The device is available in 1.5-V, 1.8-V, 2.5-V, 3.3-V, 5-V, and adjustable-output voltage options. All internal circuitry is designed to operate down to 1-V input-to-output differential. Dropout voltage is specified at a maximum of 1.3V at 800mA, decreasing at lower load currents.

Device Information
ORDER NUMBERPACKAGE (PIN)BODY SIZE
TLV1117DCYSOT-223 (4) 6.50 mm × 3.50 mm
TLV1117DRJSON (8)4.00 mm × 4.00 mm
TLV1117KVUTO-252 (3)6.60 mm × 6.10 mm
TLV1117KCSTO-220 (3)10.16 mm × 8.70 mm
TLV1117KCTTO-220 (3)10.16 mm × 8.59 mm
TLV1117KTTDDPAK, TO-263 (3)10.18 mm × 8.41 mm
