TLV1117-50技术文档下载：
TLV1117-50 - 产品图解：
TLV1117-50 - 单输出 LDO、800mA、固定电压 (5.0V)、内部电流限制、过热保护
TLV1117-50是TI公司的一款单通道LDO产品，TLV1117-50是单输出 LDO、800mA、固定电压 (5.0V)、内部电流限制、过热保护，本页介绍了TLV1117-50的产品说明、应用、特性等，并给出了与TLV1117-50相关的TI元器件型号供参考。
TLV1117-50 - 单输出 LDO、800mA、固定电压 (5.0V)、内部电流限制、过热保护 - 单通道LDO - 线性稳压器(LDO) - TI公司（Texas Instruments，德州仪器）
产品特性
- 1.5-V, 1.8-V, 2.5-V, 3.3-V, 5-V, and Adjustable-Output Voltage Options
- Output Current of 800 mA
- Specified Dropout Voltage at Multiple Current Levels
- 0.2% Line Regulation Maximum
- 0.4% Load Regulation Maximum
产品应用
- Electronic Points of Sale
- Medical, Health, and Fitness Applications
- Printers
- Appliances and White Goods
- TV Set-Top Boxes
产品说明
The TLV1117 device is a positive low-dropout voltage regulator designed to provide up to 800mA of output current. The device is available in 1.5-V, 1.8-V, 2.5-V, 3.3-V, 5-V, and adjustable-output voltage options. All internal circuitry is designed to operate down to 1-V input-to-output differential. Dropout voltage is specified at a maximum of 1.3V at 800mA, decreasing at lower load currents.
Device Information
| ORDER NUMBER | PACKAGE (PIN) | BODY SIZE |
|---|---|---|
| TLV1117DCY | SOT-223 (4) | 6.50 mm × 3.50 mm |
| TLV1117DRJ | SON (8) | 4.00 mm × 4.00 mm |
| TLV1117KVU | TO-252 (3) | 6.60 mm × 6.10 mm |
| TLV1117KCS | TO-220 (3) | 10.16 mm × 8.70 mm |
| TLV1117KCT | TO-220 (3) | 10.16 mm × 8.59 mm |
| TLV1117KTT | DDPAK, TO-263 (3) | 10.18 mm × 8.41 mm |
