TPD4S009 - 产品图解：
TPD4S009-用于高速差分接口的 4 通道 ESD 解决方案
TPD4S009-高性能TVS二极管-ESD保护二极管-接口
TI芯片：
承诺原装正品
专营TI德州仪器，真正优化您的供应链
TI产品 - TPD4S009介绍

TPD4S009 - 用于高速差分接口的 4 通道 ESD 解决方案

TPD4S009是TI德州仪器公司的一款高性能TVS二极管产品，TPD4S009是用于高速差分接口的 4 通道 ESD 解决方案，本站介绍了TPD4S009的封装应用图解、特点和优点、功能等，并给出了与TPD4S009相关的TI元器件型号供参考。

TPD4S009 - 用于高速差分接口的 4 通道 ESD 解决方案 - 高性能TVS二极管 - ESD保护二极管 - 德州仪器

产品特性
  • IEC 61000-4-2 Level 4 ESD Protection
    • ±8-kV Contact Discharge
  • IEC 61000-4-5 Surge Protection
    • 2.5A (8/20µs)
  • I/O Capacitance: 0.8 pF (Typical)
  • Low Leakage Current: 10 nA (Typical)
  • Supports High-Speed Differential Data Rates (3-dB Bandwidth > 4 GHz)
  • Ultra-low Matching Capacitance Between Differential Signal Pairs
  • Ioff Feature for the TPD4S009
  • Industrial Temperature Range: –40°C to 85°C
  • Easy Straight through Routing, Space-Saving Package Options
产品应用
  • End Equipment
    • Set-Top Boxes
    • DTVs
    • Laptop/Desktop
    • Electronic Point of Sale (EPOS)
  • Interfaces
    • USB 2.0
    • HDMI 1.4
    • LVDS
    • SATA
    • Ethernet
    • FireWire
产品说明

The TPD4S009 and TPD4S010 are four-channel TVS diode arrays for electrostatic discharge (ESD) protection. TPD4S009 and TPD4S010 are rated to dissipate contact ESD strikes at the maximum level specified in the IEC 61000-4-2 international standard (Level 4), with ±8-kV contact discharge ESD protection. The low capacitance (0.8-pF) of these devices, coupled with the excellent matching between differential signal pairs (0.05-pF line-line capacitance for the TPD4S009DRY) enables this device to provide transient voltage suppression circuit protection for high-speed differential data rates (3-dB bandwidth > 4 GHz).

The TPD4S009 is offered in DBV, DCK, DGS, and DRY packages. The TPD4S009DRYR is the most space saving package option available for dual pair high-speed differential lines. The TPD4S010 is offered in the industry standard DQA package. The TPD4S009DGSR and TPD4S010DQAR offer flow-through board layout options to reduce signal glitches normally caused by routing mismatches between the D+ and D- signal pair. See also TPD4E05U06DQAR which is P2P compatible with TPD4S010DQAR. This device offers higher IEC ESD protection, lower capacitance, lower RDYN, lower DC breakdown voltage, and lower clamping voltage.

产品器件信息
PART NUMBERPACKAGEBODY SIZE (NOM)
TPD4S009SOT (6)2.90 mm × 1.60 mm
2.00 mm × 1.25 mm
VSSOP (10)3.00 mm × 3.00 mm
USON (6)1.45 mm × 1.00 mm
TPD4S010USON (10)2.50 mm × 1.00 mm
