TPS62080A - 采用 2x2mm SON 封装的 1.2A 高效降压转换器

TPS62080A是TI德州仪器公司的一款转换器（集成开关）产品，TPS62080A是采用 2x2mm SON 封装的 1.2A 高效降压转换器，本站介绍了TPS62080A的封装应用图解、特点和优点、功能等，并给出了与TPS62080A相关的TI元器件型号供参考。

TPS62080A - 采用 2x2mm SON 封装的 1.2A 高效降压转换器 - 转换器（集成开关） - DC/DC开关稳压器 - 德州仪器

产品特性

DCS-Control™ Architecture for Fast Transient Regulation
Snooze Mode for 6.5-µA Ultra Low Quiescent Current
2.3-V to 6-V Input Voltage Range
100% Duty Cycle for Lowest Dropout
Power Save Mode for Light-Load Efficiency
Output Discharge Function
Short-Circuit Protection
Power-Good Output
Thermal Shutdown
Available in 2-mm × 2-mm 8-Pin WSON Package

产品应用

Battery-Powered Portable Devices
Point of Load Regulators
System Power Rail Voltage Conversion

产品说明

The TPS6208x devices are a family of high frequency synchronous step down converters. With an input voltage range of 2.3 V to 6 V, common battery technologies are supported. Alternatively, the device can be used for low voltage system power rails.

The TPS6208x focuses on high efficiency step-down conversion over a wide output current range. At medium to heavy loads, the converter operates in PWM mode and automatically enters Power Save Mode operation at light load currents to maintain high efficiency over the entire load current range. To maintain high efficiency at very low load or no load currents, a Snooze Mode with an ultra-low quiescent current is implemented. This function, enabled by the MODE pin, increases the run-time of battery driven applications and keeps the standby current at its lowest level to meet green energy standards targeting a low stand-by current.

To address the requirements of system power rails, the internal loop compensation allows a large selection of external output capacitor values in excess of 100 µF. With its DCS-Control architecture, excellent load transient performance and output voltage regulation accuracy is achieved. The device is available in 2-mm × 2-mm WSON package with Thermal PAD.

产品器件信息

PART NUMBER	PACKAGE	BODY SIZE (NOM)
TPS62080	WSON (8)	2.00 mm × 2.00 mm
TPS62080A
TPS62081
TPS62082
