TL7715A是TI公司的一款无产品，TL7715A是用于 15V 系统、具有可编程时间延迟的单电源监控器，本页介绍了TL7715A的产品说明、应用、特性等，并给出了与TL7715A相关的TI元器件型号供参考。
TL7715A - 用于 15V 系统、具有可编程时间延迟的单电源监控器 - 无 - 监控器和复位IC - TI公司（Texas Instruments，德州仪器）
- Power-On Reset Generator
- Automatic Reset Generation After Voltage Drop
- Wide Supply-Voltage Range
- Precision Voltage Sensor
- Temperature-Compensated Voltage Reference
- Externally Adjustable Pulse Duration
- Computers
- Tablets
- Smart Phones
- Servers
- Music Players
The TL77xxA family of integrated-circuit supply-voltage supervisors is designed specifically for use as reset controllers in microcomputer and microprocessor systems. The supply-voltage supervisor monitors the supply for undervoltage conditions at the SENSE input. During power up, the RESET output becomes active (low) when VCC attains a value approaching 3.6 V. At this point (assuming that SENSE is above VIT+), the delay timer function activates a time delay, after which outputs RESET and RESET go inactive (high and low, respectively). When an undervoltage condition occurs during normal operation, RESET and RESET go active.
| PART NUMBER | PACKAGE | BODY SIZE (NOM) |
|---|---|---|
| TL77xxA | SOIC (8) | 4.90 mm × 3.91 mm |
| PDIP (8) | 9.81 mm × 6.35 mm |
