TPS3808G30-Q1 - 汽车类低静态电流可编程延迟监控电路
TPS3808G30-Q1是TI德州仪器公司的一款无产品,TPS3808G30-Q1是汽车类低静态电流可编程延迟监控电路,本站介绍了TPS3808G30-Q1的封装应用图解、特点和优点、功能等,并给出了与TPS3808G30-Q1相关的TI元器件型号供参考。
TPS3808G30-Q1 - 汽车类低静态电流可编程延迟监控电路 - 无 - 监控器和复位IC - 德州仪器
- Qualified for Automotive Applications
- Power-On Reset Generator With Adjustable Delay Time: 1.25ms to 10s
- Very Low Quiescent Current: 2.4μA Typical
- High Threshold Accuracy: 0.5% Typical
- Fixed Threshold Voltages for Standard Voltage Rails From 1.2V to 5V and Adjustable Voltage Down to 0.4V Are Available
- Manual Reset (MR) Input
- Open-Drain RESET Output
- Temperature Range: –40°C to 125°C
- Small SOT-23 Package
- DSP or Microcontroller Applications
- FPGA and ASIC Applications
- Automotive Vision
- Automotive Radar
The TPS3808Gxx-Q1 microprocessor supervisory circuits monitor system voltages from 0.4V to 5V, asserting an open-drain RESET signal when the SENSE voltage drops below a preset threshold or when the manual reset (MR) pin drops to a logic low. The RESET output remains low for the user-adjustable delay time after the SENSE voltage and MR return above their thresholds.
The TPS3808Gxx-Q1 device uses a precision reference to achieve 0.5% threshold accuracy for VIT ≤ 3.3 V. The reset delay time can be set to 20ms by disconnecting the CT pin, 300ms by connecting the CT pin to VDD using a resistor, or can be user-adjusted from 1.25ms to 10s by connecting the CT pin to an external capacitor. The TPS3808Gxx-Q1 has a very low typical quiescent current of 2.4μA, so it is well suited for battery-powered applications. The device is available in a small SOT-23 package and is fully specified over a temperature range of –40°C to 125°C (TJ).
For more information about TI's voltage supervisor portfolio, visit the Supervisor and Reset IC Overview Page page.
| PART NUMBER | PACKAGE | BODY SIZE (NOM) |
|---|---|---|
| TPS3808Gxx-Q1 | SOT-23 (6) | 2.90 mm × 1.60 mm |
| SON (6) | 2.00 mm × 2.00 mm |
