TPS54560 - 具有 Eco-mode 的 60V 输入、5A、降压 DC-DC 转换器

TPS54560是TI德州仪器公司的一款转换器（集成开关）产品，TPS54560是具有 Eco-mode 的 60V 输入、5A、降压 DC-DC 转换器，本站介绍了TPS54560的封装应用图解、特点和优点、功能等，并给出了与TPS54560相关的TI元器件型号供参考。

TPS54560 - 具有 Eco-mode 的 60V 输入、5A、降压 DC-DC 转换器 - 转换器（集成开关） - DC/DC开关稳压器 - 德州仪器

产品特性
  • High Efficiency at Light Loads with Pulse Skipping Eco-mode™
  • 92-mΩ High-Side MOSFET
  • 146 μA Operating Quiescent Current and 2 μA Shutdown Current
  • 100 kHz to 2.5 MHz Fixed Switching Frequency
  • Synchronizes to External Clock
  • Low Dropout at Light Loads with Integrated BOOT Recharge FET
  • Adjustable UVLO Voltage and Hysteresis
  • 0.8 V 1% Internal Voltage Reference
  • 8-Terminal HSOIC with PowerPAD™ Package
  • –40°C to 150°C TJ Operating Range
  • Supported by WEBENCH™ Software Tool
产品应用
  • Industrial Automation and Motor Control
  • Vehicle Accessories: GPS, Entertainment
  • USB Dedicated Charging Ports and Battery Chargers
  • 12 V, 24 V and 48 V Industrial, Automotive and Communications Power Systems
产品说明

The TPS54560 is a 60 V, 5 A, step down regulator with an integrated high side MOSFET. The device survives load dump pulses up to 65V per ISO 7637. Current mode control provides simple external compensation and flexible component selection. A low ripple pulse skip mode reduces the no load supply current to 146 μA. Shutdown supply current is reduced to 2 μA when the enable pin is pulled low.

Undervoltage lockout is internally set at 4.3 V but can be increased using the enable pin. The output voltage start up ramp is internally controlled to provide a controlled start up and eliminate overshoot.

A wide switching frequency range allows either efficiency or external component size to be optimized. Output current is limited cycle-by-cycle. Frequency foldback and thermal shutdown protects internal and external components during an overload condition.

The TPS54560 is available in an 8-terminal thermally enhanced HSOIC PowerPAD™ package.

Device Information
ORDER NUMBERPACKAGEBODY SIZE
TPS54560DDAHSOIC (8)4,89mm x 3,9mm
