TPS61080 - 产品图解：
TPS61080-具有集成功率二极管的 27V、500mA 开关、1.2MHz 升压转换器
TPS61080-背光-LED驱动器-电源管理
TI芯片：
承诺原装正品
专营TI德州仪器，真正优化您的供应链
TI产品 - TPS61080介绍

TPS61080 - 具有集成功率二极管的 27V、500mA 开关、1.2MHz 升压转换器

TPS61080是TI德州仪器公司的一款背光产品，TPS61080是具有集成功率二极管的 27V、500mA 开关、1.2MHz 升压转换器，本站介绍了TPS61080的封装应用图解、特点和优点、功能等，并给出了与TPS61080相关的TI元器件型号供参考。

TPS61080 - 具有集成功率二极管的 27V、500mA 开关、1.2MHz 升压转换器 - 背光 - LED驱动器 - 德州仪器

产品特性
  • 2.5-V to 6-V Input Voltage Range
  • Up to 27-V Output Voltage
  • 0.5-A Integrated Switch (TPS61080) 1.3-A Integrated Switch (TPS61081)
  • 12-V/400-mA and 24-V/170-mA From 5-V Input (Typical)
  • Integrated Power Diode
  • 1.2-MHz/600-kHz Selectable Fixed Switching Frequency
  • Input-to-Output Isolation
  • Short-Circuit Protection
  • Programmable Soft Start
  • Overvoltage Protection
  • Up to 87% Efficiency
  • 10-Pin 3-mm × 3-mm QFN Package
产品应用
  • 3.3-V to 12-V, 5-V to 12-V, and 24-V Boost Converter
  • White LED Backlight for Media Form Factor Display
  • OLED Power Supply
  • xDSL Applications
  • TFT-LCD Bias Supply
  • White LED Flash Light
产品说明

The TPS6108x is a 1.2 MHz/600 kHz fixed-frequency boost regulator designed for high integration, which integrates a power switch, an I/O isolation switch, and a power diode. When a short-circuit condition is detected, the isolation switch opens up to disconnect the output from the input. As a result, the IC protects itself and the input source from any pin, except VIN, from being shorted to ground. The isolation switch also disconnects the output from input during shutdown to prevent any leakage current. Other provisions for protection include 0.5 A/1.3 A peak-to-peak overcurrent protection, programmable soft start (SS), over voltage protection (OVP), thermal shutdown, and under voltage lockout (UVLO).

The IC operates from input supplies including single Li-ion battery, triple NiMH, and regulated 5 V, such as USB output. The output can be boosted up to 27 V. TPS6108x can provide the supply voltages of OLED, TFT-LCD bias, 12-V and 24-V power rails. The output of TPS6108x can also be configured as a current source to power up to seven WLEDs in flash light applications.

产品器件信息
PART NUMBERPACKAGEBODY SIZE (NOM)
TPS61080VSON (10)3.00 mm × 3.00 mm
TPS61081
