TPS79333 - 产品图解：
TPS79333-超低噪声、高 PSRR、快速射频、高电平启用的 200mA 低压降稳压器
TPS79333-单通道LDO-线性稳压器(LDO)-电源管理
TPS79333-TPS793 Low-Noise, High PSRR, RF, 200-mA Low-Dropout Linear Regulators in NanoStar? Wafer Chip Scale and SOT-23
TI芯片：
承诺原装正品
专营TI德州仪器，真正优化您的供应链
TI产品 - TPS79333介绍

TPS79333 - 超低噪声、高 PSRR、快速射频、高电平启用的 200mA 低压降稳压器

TPS79333是TI德州仪器公司的一款单通道LDO产品，TPS79333是超低噪声、高 PSRR、快速射频、高电平启用的 200mA 低压降稳压器，本站介绍了TPS79333的封装应用图解、特点和优点、功能等，并给出了与TPS79333相关的TI元器件型号供参考。

TPS79333 - 超低噪声、高 PSRR、快速射频、高电平启用的 200mA 低压降稳压器 - 单通道LDO - 线性稳压器(LDO) - 德州仪器

产品特性
  • 200-mA RF Low-Dropout Regulator With Enable
  • Available in Fixed-Voltage Versions from 1.8 V to 4.75 V and Adjustable (1.22 V to 5.5 V)
  • High PSRR (70 dB at 10 kHz)
  • Low Noise (32 μVRMS, TPS79328)
  • Fast Start-Up Time (50 μs)
  • Stable With a 2.2-μF Ceramic Capacitor
  • Excellent Load and Line Transient Response
  • Very Low Dropout Voltage (112 mV at 200 mA, TPS79330)
  • 5- and 6-Pin SOT23 (DBV) and NanoStar Wafer Chip Scale (YZQ) Packages
2 Applications
  • RF: VCOs, Receivers, ADCs
  • Audio
  • Cellular and Cordless Telephones
  • Bluetooth®, Wireless LAN
  • Handheld Organizers, PDAs
产品说明

The TPS793 family of low-dropout (LDO) low-power linear voltage regulators features high power-supply rejection ratio (PSRR), ultralow-noise, fast start-up, and excellent line and load transient responses in NanoStar™ wafer chip scale and SOT23 packages. NanoStar packaging gives an ultrasmall footprint as well as an ultralow profile and package weight, making these devices ideal for portable applications such as handsets and PDAs. Each device in the family is stable, with a small, 2.2-μF ceramic capacitor on the output. The TPS793 family uses an advanced, proprietary BiCMOS fabrication process to yield extremely low dropout voltages (for example, 112 mV at 200 mA, TPS79330). Each device achieves fast start-up times (approximately 50 μs with a 0.001-μF bypass capacitor) while consuming very low quiescent current (170 μA typical). Moreover, when the device is placed in standby mode, the supply current is reduced to less than 1 μA. The TPS79328 exhibits approximately 32 μVRMS of output voltage noise at 2.8-V output with a 0.1-μF bypass capacitor. Applications with analog components that are noise-sensitive, such as portable RF electronics, benefit from the high PSRR and low-noise features as well as the fast response time.

产品器件信息
PART NUMBERPACKAGEBODY SIZE (NOM)
TPS793SOT-23 (6)2.90 mm × 1.60 mm
SOT-23 (5)2.90 mm × 1.60 mm
DSBGA (5)1.35 mm × 1.00 mm
